P-Rob 3
Joined ATTA on October 2021
P-Rob 3
source: F&P Robotics AG
Description
The P-Rob 3 is a robot arm designed to be easily handled. User can apply different module for different applications. It features a user-friendly design with simple buttons for configuration. It can be easily transported due to its detachab
Details
Features and specs
Availability
Name
P-Rob 3
Manufacturer
F&P Robotics AG
Release date
October 2019
Country of Origin
Others
Core Function
Picking/sorting
Robot series
Dimensions
R320° | D152.8*H1137.5mm
Weight
20 kg
Power
[Electric (w/o battery)] AC: 100 - 240 V, 600 W max., 50/60 Hz | DC: 22 - 28V, 12.5 A, <80 W (24V version) | 45 - 49V, 12.5A, <100W (48V)
Connectivity
[Wired] Ethernet + USB (Wi-Fi request needed)
Operation environment
Mounting Position: Floor, table, wall, ceiling, linear axis on request, mobile plattform on request
Other specifiacations
Payload: 3 - 5 kg | Footprint: 290*250mm | Reach: 775 mm | Degrees of freedom: 6°
Current availability
Discontinued
Available Countries
Germany | Switzerland
Industry
Manufacturing | Construction & infrastructure | Professional, scientific and technical activities
Price
From €2500
