Reach Bravo 2

Joined ATTA on July 2021

Bravo 2

source: Blueprint Lab

My keywords

Description

The Reach Bravo 2 is an articulated magic arm that can be mounted on ROVs and underwater robots. Its max lift capacity reach up to 20kg enables close, complex inspection for inspection-class ROVs and existing fleets.

Details

Features and specs

Availability

Name

Reach Bravo 2

Manufacturer

Blueprint Lab

Release date

January 2023

Country of Origin

United States

Core Function

Picking/sorting,Others

Robot series

Links

Profile author

Last Updated: April 27, 2023

Dimensions

W137*L460mm | outer diameter: 84mm

Weight

Air: 2.8kg | Water: 1.6kg

Power

[Wired] voltage:24 to 48V|wattage:60W

Connectivity

[Wired] RS485/Ethernet

Operation environment

Water pressure resistance:300MST|Temperature:10°C to 35°C

Other specifiacations

Material: AL6061 | Full reach lift: 20kg | Max lift capacity: 20 kg | Joint speed: 45°/s nominal | Joint accuracy: 0.1° | Push rod linear force: 1000N | Connector cable: 13 Pin Ethernet suvcon (DBH13M) | Torque: 20Nm | Control unit: Space Mouse/Software GUI/Topside master arm | Optional sensor interface: PWR+232+485+Ethernet | Controll modes: Position/verocity

Current availability

To Purchase/Lease

Available Countries

Australia

Industry

Emergency and Hazardous Operations | Electricity / gas / steam / air conditioning supply | Manufacturing | Mining / quarrying | Professional, scientific and technical activities | Public services

Price

Not announced
